Sojet

High Speed and High Performance
Printing speed up to 200m/min (300×300DPI)
The speed of code printing up to 79pcs/sec.
Supports continuous printing without gap

Hight Reliability
Unique nozzle control tech
Real-time temperature control
Alternate nozzle printing
Higher printing quality
Longer service life

Flexible Options
Horizontal DPI range from (40~1200DPI)
Resolution: 600×1200DPI
Function/Communication/I/O customization

Printing Involved Industries
Food and Beverage, pharmaceutical,
Industrial, tobacco etc.
OEM/ODM service available

Parameter Details
Technology HP TIJ 2.5 Thermal Inkjet Technology
Resolution Vertical: 600 dpi; Horizontal: 40-1200 dpi (Single head)
Communication Protocol Plain code protocol, easy for system integration and secondary development
Screen 7 inches color capacitive touch screen
Dimensions Controller: 224×151×138mm
Print head: 145×91×47mm
Language Chinese, English, Korean, Spanish, Japanese, French, German, Italian, Turkish
Keyboard Chinese, English, Korean, Arabic, Russian, Spanish, French, German
Counter Ordinary counter, the carry bit source can be set flexibly
Printing Height 1~25.4mm (Two printheads, free combination)
Printing Speed Up to 200m/min
Printing Performance The speed of QR code printing is up to 79pcs/sec.
Supported Barcode Codebar, Code25, Code39, Code93, Code128, UPCA, UPCE, EAN, QR Code (GS1 supported), Data Matrix (GS1 supported), Grid Matrix, Maxicode, PDF417 (Others upon request)
Date Format The date format can be set flexibly
Interface
  • Ethernet interface*
  • USB interface* (USB flash drive, scanner, and auxiliary communication equipment)
  • 12-pin aviation interface* (1 alarm kit, RS232, external I/O input)
  • 17-pin aviation interface* (2 external photocell and encoder input)
  • 17-pin aviation interface (connect with printhead *2)
Ink Management
  • Recognize the ink type and choose the best suitable parameters automatically
  • Only original HP cartridges are supported
  • Automatic measurement system for ink consumption
Set up Automatic inkjet detection and printing of known heights. Optional Spring-back mechanism.
Environment Requirements Working environment: -10°C ~ +55°C; Equipment storage environment: -20°C ~ +70°C
Input Power AC 100-240V/50-60Hz
Output Power 24.0V 4A, 96.0W
Product Certification CE, FCC
